Piston valve VS-125DA-3P

pneumaticstopdrain

Veson valve ltd 3 position pneumatic actuators provide an operation of 0°- 45°- 90°. The intermediate position is achieved by an external mechanical stop of movement on the 2 auxiliary pistons (for spring return actuators it may be only one auxiliary piston). This intermediate stop position is adjustable from 0° to 90°, for example 5°, 20°, 30° 50°, 75° etc. The intermediate position is easily achieved by adjusting the external nuts located outside the two end-caps. Both type, double acting and spring return, are available. Field of application: For dosing, for exact filling and for any kind of services where on 90° rotation an intermediate stop position is desired A182 F92 body material available on select models. Lockout feature integrated into handle adaptor, which accommodates customer’s lockout device in open and closed positions. Handle can be repositioned to any location along its length. Can be applied as a T-handle or used full length. Flow arrow forged into mounting flange visible above insulation. Complies with ASME B16.34 requirements. Socketweld ends per ASME B16.11. Blank configuration for buttweld and customer end connections. Actuator mounting per MSS SP-101.
