Spray nozzle PC seriesfor liquidshollow-conebrass
Add to favorites
Compare this product
Characteristics
- Function
- spray
- Fluid
- for liquids
- Stream
- hollow-cone
- Material
- brass
- Spray angle
- 90°
- Other characteristics
- female, tangential
- Flow
Min.: 0.69 l/min
(0.18 us gal/min)Max.: 7.12 l/min
(1.88 us gal/min)- Pressure
Min.: 0.5 bar
(7.3 psi)Max.: 10 bar
(145 psi)
Description
PC series hollow cone nozzles are tangential nozzles, which produce a hollow cone spray of atomized droplets.
As they have a large free passage and no swirling vane inside their body, they minimize clogging.
The PC series is characterized by a hand wheel, which allows the user to regulate the flow of the nozzle.
