Helical gear gearbox PD/PM seriesright angle50 - 100 Nm200 - 500 Nm
Add to favorites
Compare this product
Characteristics
- Type
- helical gear
- Shaft orientation
- right angle
- Torque
- 50 - 100 Nm, 200 - 500 Nm, 100 - 200 Nm, 500 - 1000 Nm, 1 - 2 kNm, 20 - 50 Nm, 2 - 5 kNm, > 10 kNm, 5 - 10 kNm, 10 - 20 Nm, 1 - 5 Nm, 5 - 10 Nm
- Configuration
- flange
- Applications
- drive, conveyor, shaft, for electric motors
- Other characteristics
- high-quality, mounted
- Rotational speed
Min.: 0.2 rpm
(1.26 rad.min-1)Max.: 360 rpm
(2,261.95 rad.min-1)- Power
Min.: 0.12 kW
(0.16 hp)Max.: 200 kW
(271.92 hp)
Description
PD / PM series parallel shaft mounted gear units produced with hollow shaft or solid shaft are commonly preferred in conveyor drive systems.
Helical gear units with parallel axis input and output.
A rigid structure in case.
System resistance calculations are made in accordance with ISO, DIN and NIEMANN standards.
Different input options may be provided (Coupled motor, IEC, PAM, W, Servo motor connected, ...).
Different output options available (Solid shaft, Hollow shaft, With shrink disc, ...).
Different mounting accessories available (B5 flange, B14 flange, Rubber buffer for torque arm, ...).
Cases are manufactured from sfero (GGG 40-50) and peak (GG 20-25).
Gears are made of cast and 21NiCrMo2 case-hardening steel.
High-quality bearing and sealing components are used.
Special requests of the customers may be considered.
