Oil pump JEV serieselectricgearstationary
Add to favorites
Compare this product
Characteristics
- Fluid
- oil
- Operation
- electric
- Technology
- gear
- Mobility
- stationary
- Domain
- industrial
- Applications
- transfer, lift
- Material
- steel
- Voltage
- 400 V, 230 V
- Protection level
- ATEX
- Other characteristics
- suction, horizontal mount, adjustable, built-in, vertical-mount
- Flow
0.54 m³/h, 0.9 m³/h
(19.06992 ft³/h, 31.7832 ft³/h)- Head
Max.: 250 m
(820'02" )Min.: 0 m
(0'00" )- Fluid temperature
Max.: 60 °C
(140 °F)Min.: -10 °C
(14 °F)
Description
Electric gear pumps
Descriptive
Technical data:
Special electric oil gear pump
Built-in and adjustable bypass
Orifice Ø: 1"F
For JEV44 and JEV45, transfer: from 50 to 2000 Cst (mm2/s)
Positioning: horizontal or vertical
Maximum suction lift: 7 metres (oil at 100 mm2/s) 3 to 5 metres (oil at 500 mm2/s)
Rotation speed: 1250 rpm (JEV42), 1450 rpm (JEV42-12B, JEV43, JEV43-12B), 1400 rpm (JEV44, JEV45, JEV44-P)
Current: 6 (JEV42, JEV44, JEV44-P), 3.8 (JEV42-12B), 2.5 (JEV43), 1.5 (JEV43-12B), 2.7 (JEV45)
Orifice Ø: 1"F
Max. TDH: 250 metres (JEV42, JEV43), 120 metres
Specifications and advantages:
Electric gear pump with an ATEX motor
Characteristics
Fluid - Oil
Technology - Gear
ATEX - No
Pump - Bare
Orifice - 1"F
Materials - Cast-iron
Mechanism - Steel
