Water pump JEV seriesoilfor dieselelectric
Add to favorites
Compare this product
Characteristics
- Fluid
- water, oil, for diesel
- Operation
- electric
- Priming
- self-priming
- Technology
- side-channel
- Mobility
- stationary
- Domain
- industrial
- Voltage
- 400 V, 230 V
- Protection level
- ATEX
- Other characteristics
- suction
- Flow
5.3 m³/h, 5.9 m³/h, 9 m³/h, 15 m³/h
(187.16773 ft³/h, 208.35653 ft³/h, 317.832 ft³/h, 529.72 ft³/h)- Head
15 m, 17 m, 24 m, 25 m, 42 m
(49'02" , 55'09" , 78'08" , 82'00" , 137'09" )- Power
0.75 kW, 0.9 kW, 1.5 kW, 1.8 kW
(1.02 hp, 1.22 hp, 2.04 hp, 2.45 hp)- Fluid temperature
Max.: 130 °C
(266 °F)Min.: -15 °C
(5 °F)
Description
2-way electric pumps
Descriptive
Technical data:
Self-priming pump
Flow reverser; two rotation directions
Maximum relative humidity: 80%
Maximum suction lift: 5 metres
Sleeves: Ø 25 millimetres (JEV302, JEV303), 30 millimetres (JEV304, JEV305), 40 mm (JEV308, JEV309), Ø 50 millimetres (JEV310, JEV311)
Orifice Ø: 1" (JEV302, JEV303), 1"1/2
Power: 1.5 (JEV302, JEV303, JEV310), 0.75 (JEV304, JEV305), 0.9 (JEV308, JEV309), 1.8 (JEV311)
Current: 8.8 (JEV302), 3.6 (JEV303), 4.8 (JEV304), 1.6 (JEV305), 5.5 (JEV308), 1.9 (JEV309), 11.8 (JEV310), 11.2 (JEV311)
Specifications and advantages:
2-way electric pump
Characteristics
More Information
Fluid - Water with low solids contect, Seawater, Diesel
Technology - Side channel
ATEX - No
Pump - Bare
Orifice - 1", 1"1/2, 2"
Materials - Brass
Mechanism - Bras
