Impeller pump JEP seriesfor chemicalsfor wineoil
Add to favorites
Compare this product
Characteristics
- Technology
- impeller
- Fluid
- for chemicals, for wine, oil, for diesel
- Operation
- diesel
- Mobility
- stationary
- Domain
- industrial, for the chemical industry, for the cosmetics industry
- Applications
- service, lift
- Voltage
- 230 V
- Protection level
- ATEX
- Other characteristics
- suction
- Flow
6.9 m³/h, 10 m³/h
(243.6712 ft³/h, 353.14667 ft³/h)- Head
Min.: 0 m
(0'00" )Max.: 30 m
(98'05" )- Power
1.5 kW
(2.04 hp)
Description
Reversible 2-way service pumps
Descriptive
Technical data:
Reversible pump (2-way)
Orifices: 1’’1/2 M
Particle size: 10 millimetres
Maximum suction lift: 6 metres
Type of impeller: NBR
Current: 7.9
Rotation speed: 900 rpm (JEP112-900-NBR), 1400 rpm (JEP112-1400-NBR)
Max. viscosity: 1500 cPo (JEP112-900-NBR), 500 cPo (JEP112-1400-NBR)
Specifications and advantages:
Reversible 2-way service pump
Characteristics
Fluid - Diesel, Oil, Food liquids, Chemical liquids, Cosmetic liquids, Pharmaceutical liquids, Wine
Technology - Flexible impeller
ATEX - No
Pump - Bare
Orifice - 1’’1/2 M
Materials - Stainless steel
Mechanism - NBR impeller
