LED display 10043747 relayRS-485Modbus RTU
Add to favorites
Compare this product
Characteristics
- Screen type
- LED
- Applications
- relay
- Interface
- RS-485, Modbus RTU
- Structure
- compact
- Configuration/mounting
- external
- Protection level
- IP54
- Other characteristics
- programmable
- Length
95.8 mm
(3.772 in)- Width
48 mm
(1.8898 in)- Height
59.15 mm
(2.3287 in)
Description
Intro - 8 Digit display in DIN-enclosure 96 X 48 mm, 0/4-20mA / 0-10V Input , All inputs and outputs optically isolated, Serial port for PC based programming
Electrical Data -
Supply Voltage - 8 -26V DC
External Sensor Supply - +Vs
General Data -
Max. Counting Range - -9999…+99999
Input Type - 0-20mA / 4-20mA / 0-10V
Digital Outputs 1…4 - 2 Relay Outputs (Programmable)
Serial Ports - RS485 (Modbus RTU)
Display - 6 Digit, 7 Segment LED, 14.4mm Digit Height
Mechanical Data -
Operating Temperature - 0°C to 50°C / 32°F to 122°F
Weight - 250 g
Sealing - Front: IP54 / Rear: IP20
Panel Cut-Out - 92 x 43 mm
