Hydraulic press 125 DM2LVmotorizedpneumaticforming
Add to favorites
Compare this product
Characteristics
- Operation
- hydraulic, motorized, pneumatic
- Function
- forming
- Structure
- straight-side, eccentric, roller, double connecting rod
- Control
- automatic
- Other characteristics
- fixed
- Force
1,250 kN
- Stroke
Min.: 10 mm
(0.394 in)Max.: 450 mm
(17.717 in)- Hydraulic pump power
21 kW
- Weight
14,500 kg
(31,967 lb)
Description
longitudinal eccentric shaft, slide with 4 linear guideways and 8 roller pads, automatic and centralized lubrication, hydraulic safety, pneumatic clutch-brake group, planetary gearbox, balancing cylinders, motorized slide adjustment.
Fixed stroke length included between the declared values.
RATED TONNAGE POINT - mm - 2.5
ENERGY AT NOMINAL SPEED - J - 5.800
NOMINAL SPEED - Spm - 74
VARIABLE SPEED - Spm - 30 - 280
BOLSTER AREA - mm - 1.300 x 800
SLIDE AREA - mm - 1.300 x 800
