Variable-angle notching machine Prisma 500

Variable notching possibilities for mullion and transom combinations, e.g. curtain walls, winter garden, sky lights and special designs • Manual adjustment of the horizontal blade max. 20mm to the front to cut slots • Notch variation: rectangle, one sided angular, two sided angular, three sided angular • Notch dimensions: 185mm horizontal, and 210mm vertical at (90°) • Profile dimensions: height maximum 280mm, width maximum 300mm • Manual adjustment of saw blade height, positioning via mechanical digital display; electronic display optional • Swivelling range vertical saw blade 30°-90°-30° (back/mid/front) positioning via mechanical digital display • Swivelling range of both, horizontal and vertical saw blade, 30°-90°-30°, positioning by mechanical digital display • Material fence on the table swivelled left / right 30°-90°-30°, positioning by scale • Depth stop adjustable via hand wheel and slide, read out by mechanical digital display, manual clamping • Semi-automatic precise and safe notching due to the work piece is fixed on the table during the cut
