Electric stacker truck CW series
manualwalk-behind12 V

electric stacker truck
electric stacker truck
electric stacker truck
electric stacker truck
electric stacker truck
electric stacker truck
Add to favorites
Compare this product


Characteristics

Energy
electric, manual
Operator
walk-behind
Voltage
12 V
Other characteristics
straddle, counterbalanced, with adjustable fork
Carrying capacity

200 lb, 400 lb, 600 lb, 800 lb, 1,000 lb
(90.7 kg, 181.4 kg, 272.2 kg, 362.9 kg, 453.6 kg)

Lifting height

62 in, 74 in

Height of mast when lowered

1 in

Overall width

27 in

Overall length

36 in, 41 in

Weight

Min.: 750 lb
(340.19 kg)

Max.: 1,475 lb
(669.05 kg)

Description

Powered lift, manual drive stackers. Counterweight design eliminates front straddle legs making this stacker ideal for feeding machinery, lifting to docks or mezzanines or anywhere that extended base legs could cause interference. Works with open and closed bottom pallets. All of our CW Series Stackers are part of our Always-In-Stock Program and are available for shipping within one week. •Lifting speed - 5" per second •Forks adjust from 6-1/2" to 20" O.D. •15-1/2" high fork backs •Heavy-duty C100 foot-operated floor lock •12V 75 amp hour WLA Battery •1" thick x 3" wide adjustable solid steel forks •Hinged door with capacity display •LED dash mount – diagnostic display • 3 position “Comfort Cushion” push handle •Quick-connect battery cables

VIDEO
