Hydraulic bending machine W24S-75

profilesectionautomatic

Full hydraulic cnc profile bending machine automatic channel angle steel section bending machine 1, Main usage hydraulic 3 roller type profile bending machine, which mainly use in various steel profile bending. It can roll “O” spiral and etc. shape workpieces. It is widely in petrol, chemical, shipyard, metal working and machine manufacturing industries. 3.Main structure of machine Full hydraulic cnc profile bending machine automatic channel angle steel section bending machine W24S-75 has machine body, side roller part, support roller part, electrical system, and hydraulic system. Machine body is a whole welded structure, the left and right running arms are installed in machine body, which drove by two hydraulic pumps, and do arc up and down movements. Support rollers are installed on two head of machine body, which can turn to various angles to suit for kinds of profile bending. 4.Function, working process and working field 4.1 Machine function Full hydraulic cnc profile bending machine automatic channel angle steel section bending machine Three rollers are main drove, can do the pre-bending, through adjusting the guide rollers, it is easy to correct the deformation from the bending process. 4.2 Working process It can do pre-bending, and its process shown as following: 4.3 Working field Full hydraulic cnc profile bending machine automatic channel angle steel section bending machine The main parameters on form means the max. bending capacity with best working efficiency. If other steel profile like square, angle, only if the bending resistant modulus less than 75 cm3, then it is available to finish bending on this W24S-75
