RECOMMENDED FOR:
Medium/hard rock breaking
Heavy and long-lasting applications
Excavators with monolithic boom
Primary breaking in quarrying
Frequent use
Equipment weight 630 Kg
Carrier's weight min/max 9/15 ton
Total height 1994 mm
Tool diameter 100 mm
Useful lenght of standard tools 520 mm
Oil flow min/max 90/110 l/min
Working pressure min/max 165/175 bar
Blows per minute 538/720 1/min
Impact energy 3602 joule
