The Laser Safety Filter 0265 is suitable for powerful Yb:YAG/Disk (1030 nm), Nd:YAG (1064 nm), Fiber (1060 - 1080 nm), Telecom (1320 nm) and CO2 (10600 nm) Laser in particular, but the filter also covers additional laser wavelengths. The laser safety filter consists of a light grey, laminated mineral glass, and offers a very good visual light transmission (VLT) of 60% despite its minor filter thickness. The laser safety filter is CE certified in accordance with the requirements of EN 207.
Certified protection specifications for EN 207
Wavelengths - Protection levels
745-817 - DIRM LB1 (OD1+)
>817-845 - DIRM LB2 (OD2+)
>845-889 - DIRM LB4 (OD4+)
>889-899 - DIRM LB5 (OD5+)
>899-924 - DIRM LB7 (OD7+)
>924-939 - DIRM LB8 (OD8+)
>939-1085 - D LB8 + IRM LB9 (OD9+)
>1085-1100 - DIRM LB8 (OD8+)
>1100-1185 - DIRM LB7 (OD7+)
>1185-1400 - DIRM LB6 (OD6+)
>1400-2292 - DI LB4 + R LB3Y + M LB4Y (OD4+)
>2292-2592 - DI LB3 + RM LB3Y (OD3+)
>2592-2725 - DIRM LB2 (OD2+)
>2725-3893 - DI LB3 + RM LB3Y (OD3+)
>3893-3977 - DI LB4 + R LB3Y + M LB4Y (OD4+)
>3977-11000 - DI LB5 + R LB3Y + M LB5Y (OD5+)
PF CE
