Handheld planer DH 40

for wooddouble-sidedelectric

Load bearing components are all made of die-cast aluminium, with milled seats for bearings and spindles. These characterics are essential for vibration-free, smooth thicknessing of soft and hard woods. Triple-spindled table (of die-cast aluminium, flat-milled) which can be accurately adjusted to 1/10mm by handwheel (zero adjustable). Automatic even feed with anti-kickback device: The knurled, spring-mounted infeed roller transports even irregularly shaped work pieces. A rubber-coated outfeed roller prevents marking the newly planed surface. Precision planer block with two HSS planer blades. Technical data: 230V. 200W. 50/60Hz. Thicknessing up to 40mm thick and up to 80mm wide. Maximum depth of cut 0.8mm. Cutter speed 6,000rpm. Feed rate 4.8m/ min. Table length 232mm. Weight approx. 8kg.
