Geometric alignment system OPTALIGN

- NEW - PENTALIGN Measuring perpendicularity and parallelism of axes and planes PENTALIGN is a high accuracy rotatable pentaprism. Used in combination with an external laser source it creates a precise perpendicular laser plane to the incident beam. Furthermore the centering sensor enables the accurate adjustment of the pentaprism rotating axis to the reference laser in order to minimise the deviation of the outgoing beam. The device can be adjusted with high precision on 5 axes: vertical and horizontal offset, vertical, horizontal and axial angle. Its small size and various fixation possibilities such as magnets, tripods, rods and flanges make it the perfect tool to measure perpendicularity between spindle and base plate of drilling machines or ship rudder carrier plans. It can also be used to determine surface parallelism of wind tower segment flanges, gearbox shaft casings, press surfaces and ship propellers. Applications: * Wind tower segment flanges * Spindles and base plates * Ship rudder carrier plans and propellers * Gearbox shaft casings * Press surfaces
