Stainless steel gas spring RGP 750 Nfor the automobile industryfor industrial usecompact
Add to favorites
Compare this product
Characteristics
- Rod material
- stainless steel
- Applications
- for industrial use, for the automobile industry
- Other characteristics
- compact, adjustable
- Force
Min.: 170 daN
Max.: 9,500 daN
- Stroke
Min.: 7 mm
(0.3 in)Max.: 125 mm
(4.9 in)- Extended length
Min.: 52 mm
(2 in)Max.: 282 mm
(11.1 in)- Compressed length
Min.: 42 mm
(1.7 in)Max.: 157 mm
(6.2 in)- Body diameter
Min.: 19 mm
(0.7 in)Max.: 150 mm
(5.9 in)
Description
•Maximum inflating pressure : 150 bar
•Minimum inflating pressure : 25 bar
•Temperature limit : 0 / +70°C
•Maximum piston rod speed : 1.6 m/s
•Gas : nitrogen
•Complies with VDI safety standards.
• Very compact size
• Solid design (no welding)
