Stainless steel gas spring RGT 9500for the automobile industryfor industrial usecompact
Add to favorites
Compare this product
Characteristics
- Rod material
- stainless steel
- Applications
- for industrial use, for the automobile industry
- Other characteristics
- compact, adjustable
- Force
Min.: 350 daN
Max.: 9,500 daN
- Stroke
Min.: 10 mm
(0.4 in)Max.: 125 mm
(4.9 in)- Extended length
Min.: 116 mm
(4.6 in)Max.: 328 mm
(12.9 in)- Compressed length
Min.: 97 mm
(3.8 in)Max.: 203 mm
(8 in)- Body diameter
Min.: 32 mm
(1.3 in)Max.: 150 mm
(5.9 in)
Description
• One-piece piston and body for higher safety
• Maximum inflating pressure : 150 bar
• Minimum inflating pressure : 25 bar
• Temperature limit : 0 / +70°C
• Maximum piston rod speed : 1.6 m/s
• Gas : nitrogen
• Complies with VDI safety standards.
• Designed especially for car makers
• Solid design (no welding)
• Design and features similar to RGP but can be used with standard G 1/8’’ piping system (except RGT 350)
• Long bottom threads recommended for fixtures with screws in the upper die
• Conforms to Toyota standard : SMS DNH 3203 N
