Hydraulic piston pump PHP seriesmanualfor industrial applicationssingle-acting
Add to favorites
Compare this product
Characteristics
- Type
- piston
- Operation
- manual
- Applications
- for industrial applications
- Other characteristics
- oil, single-acting, adjustable
- Pressure
700 bar, 1,500 bar
(10,153 psi, 21,756 psi)
Description
• Hydraulic pressure proportional to air pressure
• Working cycle : advance / hold / return
• External adjustable pressure relief valve, set at:
– 700 bar for PHP 705 et 711
– 1500 bar for PHP 1530
• Oil capacity: 500, 1250 and 3000 cm³ (delivered with oil)
• Air inlet pressure: 7 bar
• Oil flow:
– PHP 705 et 711: from 700 to 50 cm³/min
– PHP 1530: from 1500 to 43 cm³/min
• Air consumption: 270 l/min (without load) under 7 bar air pressure
