Direct-operated solenoid valve R2AB NA/NO2-waynormally openfor water
Add to favorites
Compare this product
Characteristics
- Control
- direct-operated
- Ports/positions
- 2-way
- Function
- normally open
- Medium
- for water, air, for steam, for oxygen, for CO2, for vacuum
- Body
- compact, threaded, brass
- Process connection
- G 1/8
- Other characteristics
- standard, electrically-operated, electromagnetic
- DN
Min.: 1.2 mm
(0.047 in)Max.: 3 mm
(0.118 in)- Voltage
Min.: 12 V
Max.: 230 V
- Temperature
Min.: -10 °C
(14 °F)Max.: 160 °C
(320 °F)- Pressure
Min.: -1 bar
(-14.5 psi)Max.: 18 bar
(261.1 psi)
Description
FUNCTIONING
Solenoid Valve 2/2 ways
Direct Acting, N.O.
BODY MATERIAL
Brass CW617N
PIPE SIZE
From G1/8”
NOMINAL DIAMETER
From 1,2mm to 3mm
KV
From 0,045m3/h to 0,20 m3/h
SEAL
NBR, FKM, EPDM
MOPD DIFFERENTIAL PRESSURE
From 0 bar min to 18 bar max
TEMPERATURE RANGE
From -10°C to +160°C
OPTIONS
Manual Override
Electroless nickel plating
Degreased for Oxygen use
Others on request
APPLICATIONS
Water supply
Automation and industrial controls
Industrial and Noble gases Control
Coffee Machines
Air and Regriferation Compressors
Vacuum
Indutrial Oxygen
Steam generators
Ammonia
Fuel management
