CO2 incubator CS160
laboratorybiochemistryfor the food industry

CO2 incubator - CS160 - RADOBIO SCIENTIFIC CO.,LTD - laboratory / biochemistry / for the food industry
CO2 incubator - CS160 - RADOBIO SCIENTIFIC CO.,LTD - laboratory / biochemistry / for the food industry
Add to favorites
Compare this product


Characteristics

Type
CO2
Applications
laboratory, biochemistry, for the food industry
Convection
forced convection, dry
Temperature control
heating, refrigerated, low-temperature, constant temperature
Configuration
benchtop, stackable, horizontal
Temperature

Min.: 4 °C
(39.2 °F)

Max.: 60 °C
(140 °F)

Capacity

Min.: 160 l
(42.27 gal)

Rotational speed

Min.: 3 rpm
(19 rad.min-1)

Max.: 300 rpm
(1,885 rad.min-1)

Width

Min.: 632 mm
(24.88 in)

Height

Min.: 675 mm
(26.57 in)

Depth

Min.: 720 mm
(28.35 in)

Description

Cat.No. - CS160 Quantity - 1 unit Control interface - 7.0 inch LED touch operation screen Rotation speed - 2~300rpm depending on load and stacking Speed control accuracy - 1rpm Shaking throw - 50mm (Customization is available) Shaking motion - Orbital Temperature control mode - PID control mode Temperature control range - 4~60°C Temperature display resolution - 0.1°C Temperature distribution - ±0.3°C at 37°C Principle of temp. sensor - Pt-100 Power consumption max. - 1300W Timer - 0~999h Tray size - 590×465mm Maximum working height - 340mm Maximum load - 35kg Tray capacity of shake flask - 35×250ml or 24×500ml or 15×1000ml or 8×2000ml or 6×3000ml or 4×5000ml (standard with sticky pad) Timing function - 0~999.9hours Maximum expansion - Stackable up to 3 units Dimension (W×D×H) - 1000×725×620mm (1 unit); 1000×725×1170mm (2 units); 1000×725×1720mm (3 units) Internal dimension (W×D×H) - 720×632×475mm Volume - 160L Illumination - FI tube,30W Principle of CO2 sensor - Infrared (IR) CO2 control range - 0~20% CO2 display resolution - 0.1% CO2 supply - 0.05~0.1MPa is recommended Sterilization method - UV sterilization Number of settable programs - 5 Number of stages per program - 30 Data export interface - USB interface Historical data storage - 800,000 messages User management - 3 levels of user management: Administrator/Tester/Operator Ambient temperature - 5~35°C Power supply - 115/230V±10%, 50/60Hz Weight - 155kg per unit Material incubation chamber - Stainless steel Material outer chamber - Painted steel Optional item - Sliding black window; Remote monitoring
