LED display module RFK1010F-AYH-LNG

LCDTFTIPS

RFK1010F-AYH-LNG is a 10.1-inch IPS TFT LCD module with projected capacitive touch panel. It features high brightness and wide viewing angle. This module supports LVDS Interface (Low Voltage Differential Signaling). The contrast ratio of the module is 800:1 (typical value), the brightness is 900 nits (typical value), and the aspect ratio is 16:9. The PCAP touchscreen has a built-in IC GT928 which enables 5-points touch, supports I2C interface. Size (Diagonal) - 10.1 - inch Dot Matrix / Resolution - 1280 × 3(RGB) × 800 - dots Module Dimension - 257.96 × 168.6 × 9.48 - mm Viewing Area - 218 × 137 - mm Active Area - 216.96(H) × 135.6(V) - mm Dot / Pixel Pitch - 0.1695 × 0.1695 - mm Display Mode - Normally Black - View Direction - IPS - Pixel Arrangement (Pixel Configuration) - R.G.B. Vertical Stripe - Aspect Ratio - 16:9 - Backlight Type - LED, Normally White - Control Board - No - Interface - LVDS - PCAP FW Version - 0X50 - PCAP IC - GT928 or Equivalent - PCAP Interface - I2C - Detect Points - 5 - Points Touch Panel - Projected Capacitive Touch Screen, PCAP - Surface - Glare - Brightness - 900 - cd/㎡ Mounting Hole - No - Operating Temperature - -20~+70 - °C Storage Temperature - -20~+70 - °C TFT Series - High Brightness TFT LCD, IPS TFT LCD, LVDS TFT LCD Display
