Touch screen display module REN025664A-CTP

OLEDcolorgraphic

REN025664A-CTP is a graphic COF capacitive touchscreen OLED display with resolution 256x64 pixels. Module size is 85.0 × 39.8 mm; Active area size is 69.1 × 17.26 mm (2.8 inches diagonal). The capacitive touchscreen has built-in IC FT6336U, supporting 1-point touch. The additional PCB on this OLED display helps users to save time on developing PCB on their own. Also, there's an added frame with four screw holes allowing users for quick mounting. This OLED module has built-in IC SSD1322 supporting 8-bit 8080 / 6800, 4-line / 3-line SPI interfaces. Our OLED boasts high contrast ratio 10,000:1 making the visual performance stand out from traditional displays. Logic supply voltage ranges from 2.8V-3.3V, the typical value is 3V. The module works within temperature from -20℃ to +70℃; Storage temperature range is -30℃ to +80℃. Raystar provides four OLED emitting colors for you to choose from: white, yellow and green. On top of it, it also supports grayscale. REN025664A-CTP is a good fit for applications such as smart home appliances, medical equipment, dashboards, etc. Structure - COF + FR + PCB - Size (Diagonal) - 2.8 - inch Dot Matrix / Resolution - 256 × 64 - dots Module Dimension - 85.0 × 39.8 × 7.83 - mm Viewing Area - 71.1 × 19.26 - mm Active Area - 69.1 × 17.26 - mm Dot / Pixel Size - 0.248 × 0.248 - mm Dot / Pixel Pitch - 0.27 × 0.27 - mm Emitting Color - OLED, White / Yellow / Green - Support Grayscale - Yes - Display Mode - Passive Matrix - IC - SSD1322 (COF) - Interface - 6800,8080,SPI - PCAP IC - FT6336U - PCAP Interface - I2C - Detect Points - 1 - Points Touch Panel - Capacitive Touch Panel - Surface - Normal Glare - Power Supply - 3V - Duty - 1/64 Duty
