Hot air rework station BK-i310

automaticfor PCB

BK-I310 was developed with high capacity core parts and simple parts to meet competitive price and effective in required main functions. Dual-heater structure in Upper heater is our improved technique over the world, which exert better effective heating than existent rework devices such as ceramic type heating machine. Hot Air for both Up and Lower heater is fast in instruction response with automatic temperature control with time. Preheating 4 IR heaters are to prevent warp (deformation by heating) of PCB and effective in working larger PCB.. ↑ BK-i310 Main controller - High capacity 7 inch touchpanel - Cortex-A8 600Mhz CPU - 65535 Color 800X480 ↑ BK-i310 Upper/Lower heater - For TOP/Bottom Heaters, each 1200 Watt high capacity heater ( 2400 Watt) - 1~10 speed levels for temperature increase ↑ BK-i310 Infrared preheater - High capacity IR tube heaters - 4pcs of 1000W IR heaters exert max 4000W of strong preheating ↑ BK-i310 Temperature setting - Basic temperature profiles are saved for user to change and use as reference profile by knack of adjusting higher/lower temperature by 5 degrees, longer/shorter heating time by 5 seconds - Easy interface: With touchscreen click to change and save by different program name, Target temperature, speed of temperature increase (seconds), heating time at target temp(seconds), nozzle size, cooling time, alaram time - available to set different temperature for TOP/Bottom heater to prevent damage of lower part and easy save and application. (After turn on machine open specific program and apply )
