Flameless explosion vent Q-Ball® S

Flameless pressure relief for dynamic requirements. The Q-Ball® S guarantees safe indoor explosion venting in the operating area. An escape of the flames as well as pressure effects as a result of the explosion are prevented inside the Q-Ball® S by efficient cooling. A specially designed substructure and minimal power-to-weight ratio allow the Q-Ball® S to be attached directly to the oscillating system. There are no costs for extensions or conversions with the application of the newly developed spherical quenching factor, the Q-Ball® S ensures maximum venting efficiency. The required venting area can thus be reduced to a minimum. Application The Q-Ball® S, unlike conventional flameless explosion venting devices, was therefore specially developed and customized for oscillating and vibrating plant components with additional high dynamic requirements and KSt values up to 265 bar*m/s. Advantages - The only approved flameless explosion venting for oscillating and vibrating systems with high dynamic requirements. - Maximum venting efficiency due to spherical quenching factor. - Easy maintenance due to integrated inspection opening. - Integrated signalling for reliable monitoring. - Can be used flexibly indoors and outdoors. - Simple retrofitting of existing explosion vent installations possible.
