Epoxy resin HTG-16 series

injection

RESOLTECH HTG-160 / HTG-165 resin is very high TG resin system specially formulated for the manufacture of tooling and large structural composites parts requiring TG’s and service temperature up to 140 °C. Due to its low viscosity, high wetting properties and excellent air release, it is suitable for the manufacture of structures and composite parts by infusion, injection moulding. HTG-160 / HTG-165 system contains no CMR components or VOC to reduce user exposure. The stable low viscosity vs temperature makes of the HTG-160 a prime choice for infusion process. However, this system is not recommended for wet lay up or filament winding because the hardener HTG-165 is sensitive to moisture. For these applications, HTGL-160 / HTGL-166 is recommended. This system gives high inter-laminar properties thanks to its exceptional wetting properties even on aramid reinforcements. Laminates can be released from the moulds after a low temperature cure cycle (8h @ 40 °C) enabling to use of low TG plug material. Final thermo-mechanical properties will be obtained after a post curing cycle defined according later in this technical data sheet. TG >140 °C Low viscosity and excellent wetting properties High thermomechanical performances TG (°C) 140 Mix density 1.07 Mix viscosity (mPa.s) 266 Gel time on 70 mL, 4cm at 23°C 3h15m
