Valve with bellows seal HV seriesglobewith handwheelregulating
Add to favorites
Compare this product
Characteristics
- Type
- globe
- Operation
- with handwheel
- Function
- regulating
- Body
- flange, PFA-lined, cast iron
- Other characteristics
- high-pressure, standard, ISO, DIN, high-temperature, with bellows seal
- DN
Min.: 15 mm
(0.591 in)Max.: 100 mm
(3.937 in)- Pressure
16 bar
(232.1 psi)- Temperature
Min.: -60 °C
(-76 °F)Max.: 180 °C
(356 °F)
Description
Features
•High reliability due to thick-walled PFA lining: universal resistance and maximum permeation resistance
•Safety also at high pressures and temperatures due to heavy-duty bellows
•Easy to maintain: seat and plug individually replaceable
Specifications
•Design - DIN/ISO ANSI/ISA-75.08.01
•Nominal Pressure - 16 bar, Class 150
•Lining - PFA
•Housing Material - EN-JS 1049 / ASTM A395
•Face-to-Face - DIN EN 558-1 and ISO 5752 series 1, ANSI 75.08.01 Cl 150+300
•Flanges to ISO 7005-2, type B or flanges drilled to ASME B16.5 class 150, raised face
•Temperature Range - -60 °C to +180 °C (-75 °F to +360 °F)
•Certifications - EU Pressure Equipment Directive 2014/68/EU, German Clean Air Act (TA-Luft)
