Rotary transfer machine

CNCtrunnionfor bars

The Traditional Trunnion Transfer Machine with Bar Feeder holds the same remarkable characteristics of the Traditional Trunnion-type Transfer Machine, plus permitting to load the machine with a feeder, of dimensions and rigidity which vary depending on the bars’ length and diameter. Together with the cutting units, the bar feeders, suitable for bars between 3,5 and 6 meters long and with up to 60 mm. diameter, allow practically non-existent downtimes, both during the machine feeding process and the loading in the feeder itself. TOOL MONITOR Riello Tool Monitor works by monitoring the spindle motors absorption, through a direct reading inside the drives and thanks to an on-purpose developed SW. Management of pre-alarms levels and of missing tool alarms. Teach-in function. Possibility of selection via RUI interface. BK MIKRO Mechanical tool detecting system. Motorized head nearby the tool, equipped with detecting stick. Management of broken tool and of detector non-rotation alarms. Selection via RUI Interface. PART CLAMPING CONTROL SYSTEM Inductive proportional sensor system, positioned on clamping fixture at loading/unloading station. Identification and correction connected to each single clamping fixture and saved on part-program. AIR FILTER EXTRACTORS Exhaust system for smokes produced by the machine, to be mounted both in the working and in the chip conveying area. LOADING HELP DEVICES Workpiece lifting or positioning system at loading/unloading station. This device is required to aid the part load during chuck closing, where NO loading equipment is available. It can be mounted on slide, manually operated or hydraulically CNC controlled.
