Rotary transfer machine MC4 320 TT

CNC4-positionmulti-spindle

mc4 320 TT is a flexible machining cell of new generation, consisting of two machining centers, each one with two independent opposed spindles, and a 4-position APC (automatic pallet changer). A tool magazine for each spindle allows to have up to 120 tools available. The four working spindles are mounted in parallel two by two and independent each other, to assure the simplest use and the highest machining quality. On each pallet are mounted two "ROTATING" self-centring chucks to produce four parts simultaneously, working on all part 5 axes. TOOL MONITOR Riello Tool Monitor works by monitoring the spindle motors absorption, through a direct reading inside the drives and thanks to an on-purpose developed SW. Management of pre-alarms levels and of missing tool alarms. Teach-in function. Possibility of selection via RUI interface. BK MIKRO Mechanical tool detecting system. Motorized head nearby the tool, equipped with detecting stick. Management of broken tool and of detector non-rotation alarms. Selection via RUI Interface. AIR FILTER EXTRACTORS Exhaust system for smokes produced by the machine, to be mounted both in the working and in the chip conveying area. IN PROCESS CONTROL DEVICES In-process gauging device for one or more dimensions, with retro-action and dimensional correction of machining operations made in the previous station. Device installed on a fully CNC Riello control group.
