Mass flowmeter TCM-0650

Coriolisfor waterDN25 - 1"

Coriolis flow meters utilize the principle of tube resonance through which the fluid flows. They detect the phase difference generated by the Coriolis force acting on the moving fluid. The TCM-0650 meter offers numerous advantages, including the ability to simultaneously measure flow, density, and temperature, enabling precise process control. Furthermore, Coriolis technology is not dependent on fluid properties, making it suitable for a wide range of liquids and gases. These meters can be combined with the external display of the TCE 8000 series, which can be configured in different versions such as compact, wall-mounted, or panel-mounted. Additionally, it is possible to request electronics with an ATEX certificate, ensuring compliance with safety standards. PRODUCT FEATURES Version - Standard Measurement type - With contact External connections - Junction box in AISI 316L for separate display Area of use - For non-explosive atmospheres DETAILS OF THE SIGNAL INPUTS AND OUTPUTS Signal Output Type - Digital and Analog load resistance - < 620 Ω (24 V) Output details - 2 x Analog 4...20 mA + 1 x Pulses Analog output functions - Volumetric flow, Mass flow, Temperature Digital output functions - Volume, Mass, Portata Volumetrica, Mass flow Maximum pulse frequency - 10.000 Hz (in TOTAL mode: 100 Hz) External input functions - Pressure compensation REGISTRY FEATURES Number of lines that can be displayed - 1 Register functions, line 1 - Cumulative volume (resettable), Cumulative mass (resettable), Volumetric flow, Temperature, Mass flow, Density, Pressure Maximum displayable value (line 1) - 9.999.999 Minimum displayable value - -999.999
