Sprag one-way clutch FON series
with internal bearingsexternalfor integration

sprag one-way clutch
sprag one-way clutch
sprag one-way clutch
Add to favorites
Compare this product


Characteristics

Technology
sprag
Construction
with internal bearings, external, for integration, without bearing function
Applications
backstop, overrunning clutch, indexing
Torque

Min.: 220 Nm
(162.2637 ft.lb)

Max.: 25,000 Nm
(18,439.0537 ft.lb)

Diameter

Min.: 20 mm
(0.79 in)

Max.: 155 mm
(6.1 in)

Rotational speed

Min.: 630 rad.min-1
(100.27 rpm)

Max.: 2,600 rad.min-1
(413.8 rpm)

Description

for bolting to the face with sprags, available in three types Application as Backstop Overrunning Clutch Indexing Freewheel Features Integrated Freewheels FON are sprag free-wheels without bearing support. In addition to the standard type, two other types are available for extended service life and indexing accuracy.
