Cylindrical roller thrust bearing

Double direction tapered roller thrust bearings can support high bidirectional axial loads and are able to compensate a small eccentricity between shaft and housing, without negatively affecting their performance. The first design features two tapered housing washers, a flat shaft washer, two rows of tapered rollers and two two-pieced machined brass cages guided on the shaft washer. A spacer sleeve is arranged between the two housing washers in order to adjust the correct bench end play (BEP) requested by the customer. The second configuration features an intermediate washer with external housing centering. Type TTK1 Separable compact units Two-piece machined brass cage (M) guided on shaft washer (intermediate washer) Intermediate washer with internal centering on shaft Preset or adjusted BEP on customer’s request Very sensitive to misalignments Supports very high bidirectional axial loads Available with lubrication grooves and holes in outer spacer Type TTKSP Separable compact units Two-piece machined brass cage (M) guided on shaft washer (intermediate washer) Shaft washer with internal centering on shaft Preset or adjusted BEP on customer’s request Very sensitive to misalignments Support very high bidirectional axial loads Available with lubrication grooves and holes in outer spacer Type TTK2 Low cross section separable compact units Two-piece machined brass cage (M) guided on shaft washer (intermediate washer) Intermediate washer with external centering on the housing Very sensitive to misalignments
