Container trailer

3-axleconstructionlifting

• Capacity: 20 m³ - 60 m³ • Types:2 Axles, 3 Axles, 4 Axles. Semi Tipper Trailer “ Pool Type-Half Pipe”, “Box Type”, “Scrap Tipper Semi Trailer” • Weight (Empty): 5700 Kg - 9500 Kg • Tipper Chassis Axles: 12 tons or 9 tons • General used Tires : 385/65 R 22,5” or Double 12R22,5 • Tipper Trailer Chassis Metarial: Material quality standart is S355J2+N, optionel MC 700 • Tipper Box Material: Base 4 mm HB 450 (Brinell Hardness Value: 450, Abrasion Resistant Steel), Side 4 mm HB 450 materials or request and are manufactured in accordance with the thickness value. Also Tipper Semitrailer addition steel 4 mm- 5 mm support is S355J2+N. • Semi Trailer Brake: Brakes system is used according to the standards EEC 97/12, doublecircuit pneumatic • Box Back Cover: Mechanical open or hydraulic. • Trailer Electric Installation: The used Installation materials conform to the EEC 24 Certified European norms. • Lifting Foot: OMS, SAF or JOST brand 2x24 tones two cyclet lacklift system. • King Pin: 2”or 3,5” flanged bolts, resistant to high degrees of tension brakes, produced from forged steel. Easy to change thanks to screw connections. E Certified.
