Signal splitter GNSS-RAS-16

robust

The GNSS-RAS-16 is a robust, active 1-to-16 signal splitter with 10dB gain. Engineered for precise GNSS/GPS signal distribution in critical environments such as server halls, laboratories and other environments where GNSS reception is required. Frequency Range: Covers all GNSS constellations within the frequency range of 1.15 GHz to 1.63 GHz, ensuring comprehensive coverage for synchronization and distribution needs. Redundant Power Supply: Equipped with a fully redundant dual power supply system to guarantee uninterrupted signal reception for end-user devices. Can work with one or two power supplies. LED Status Indicators: Intuitive indicator LEDs monitor antenna current consumption and power supply units (PSUs), facilitating quick and efficient troubleshooting. Signal Integrity: Each splitter output is DC loaded with 200-ohm resistors to simulate antenna current draw, preventing false antenna alarms in connected receivers. The GNSS-RAS-16 delivers dependable performance and precise signal distribution, meeting the demands of environments requiring robust GNSS reception solutions.
