Hot air welding machine

ultrasonicthermalpulse

Ultrasonic Tube Sealing system is designed to be mounted as a station on all types of “inline” and “rotary” filling machines. The Ultrasonic energy is applied to the tubes present in the sealing station. Ultrasonic Sealing is a cold welding technique without heater or hot air streams making it ideally suited for cosmetics, tooth paste and pharmaceutical products. Historically, heat sealing has been the technology used on many horizontal forms of packaging machines. Although this has become the established process for many applications, it can have its drawbacks, common issues include leakages attributed to product contamination within the seal area, coarse particles such as sugar or coffee causing puncturing, odours from trapped product, and unsightly burnt edges. Ultrasonic welding is a reliable and economic alternative for typical thermal processes that ensures tight weld seals despite of product contamination. Ultrasonic welding technology is particularly well suited for packaging processes with high production rate requirements and applications with challenging process. The ultrasonic process also offers additional benefits such as cold welding/sealing process, tight sealing of films, repeatable and analyzable weld process which is not possible when using radiant heat process. Diameter of Tubes: 20 to 45mm dia Speed of Operation: 45 to 70 tubes / minute depending on the dia and material of tube Air Flow: 40 CFM at 8 kg/cm2 Mode of Operation: Constant energy / time Flat Pouches (Welding step by step) Horizontal flow pack (Continuous Welding) Tube Sealing (Plastic & Laminate tubes)
