Air rotary union RU009for oilfor vacuum2-passage
Add to favorites
Compare this product
Characteristics
- Medium
- for air, for oil, for vacuum
- Number of passages
- 2-passage
- Applications
- hydraulic, high-pressure
- Other characteristics
- ball bearing, dual-flow, shaft-mounted
- Rotational speed
Max.: 500 rpm
(3,141.59 rad.min-1)Min.: 0 rpm
(0 rad.min-1)- Pressure
Max.: 3,000 psi
Min.: 0 psi
- Nominal size
Max.: 4.45 in
Min.: 1.625 in
Description
Rotary Systems' inline dual-flow swivel union is designed for multipurpose use. This swivel union uses a hardened and ground shaft, impregnated Teflon seals, and dual ball bearings. The 009 series swivel union is able to withstand high pressures, moderate speeds, and high side loads.
Max. Air Pressure 250 PSI
Max. Vacuum Pressure 28" Hg
Max. Temperature 300° F
