6-axis CNC machining center SBA 485

verticalfor steelfor PVC

• CNC machine with 3 interpolationg CNC-axes and integrated SPS control • Approx. 60 to 140 window units per shift, depending on the specification • For the machining of: • Ventilation slots and drain slots • Dowel and transom holes • Screw connections for steel reinforcement • Tripple hole drill and gear slots • Lock case marking by drilling and punching • Drilling unit for corner and stay hinges - double drillings • All preparations can also be effected on door sashes and frames • 2 grippers for profile feeding and extraction • Data transfer by network of AV program or a precending machine through bar code • PC for the machine operation and visualisation • Infeed and removal magazine for 10 or 20 profile bars • up to 6 CNC axes • Extension of the machine stand for profile bars up to a length of 6.500 mm • Reinforcement screwing bridge • Several processing units • Receiver assembly station • Barcode scanner • Vertical notch saw unit • Adaptation to cutting centre Technical data Power (kW) : 8 Voltage (V) : 400 Operating pressure (bar) : 7 Air consumption (l/min) : approx. 900 Workable profile width (mm) : 60 - 120 Workable profile height (mm) : 55 - 120 Bar length (mm) : min. 300 (clear width), max. 3.500-6.500 Machine dimensions L x D x H (in mm) : 10.500 x 3.500 x 2.100 Weight (kg) : approx. 5.000
