Ultrasonic flow meter UQS7
ultrasonic transit-timevolumefor water

ultrasonic flow meter
ultrasonic flow meter
Add to favorites
Compare this product


Characteristics

Technology
ultrasonic, ultrasonic transit-time
Type
volume
Fluid
for water
Installation
insertion
Process temperature

Max.: 80 °C
(176 °F)

Min.: -30 °C
(-22 °F)

Process pressure

Max.: 25 bar
(362.59 psi)

Min.: 0 bar
(0 psi)

Description

This solid state flow switch provides a highly accurate monitoring and control solution for water-based fluids. Our UQS7 combines two built-in switchpoints, a 4-20mA analogue output and a digital display in a single, compact unit. Ultrasonic sensing technology measures time of flight between two discrete points, assuring highly accurate measurement with low insertion loss as compared to other types of flow sensor. Setpoints and dead-band are easily adjusted by using a built-in, user-friendly menu. Analogue output is scalable from 25% to 100% of full scale range, providing a high degree of flexibility for a wide range of applications. A 10-bit microprocessor provides built-in self diagnostics and allows for switch time delays up to 9.9 seconds. For applications requiring accurate monitoring of water-based fluids, the UQS7 is an ideal choice. FEATURES Integrated 4-20mA analogue output Easy to read LED display Fully configurable via keypad Suitable for water-based fluids IP65 protection 7 digit LED display Tamper-proof keypad lock Rotable display

Catalogs

No catalogs are available for this product.

See all of Roxspur Measurement & Control‘s catalogs
