Relative pressure transducer PREMASGARD 2125
differentialatmosphericpiezoresistive

Relative pressure transducer - PREMASGARD 2125 - S+S Regeltechnik - differential / atmospheric / piezoresistive
Relative pressure transducer - PREMASGARD 2125 - S+S Regeltechnik - differential / atmospheric / piezoresistive
Relative pressure transducer - PREMASGARD 2125 - S+S Regeltechnik - differential / atmospheric / piezoresistive - image - 2
Relative pressure transducer - PREMASGARD 2125 - S+S Regeltechnik - differential / atmospheric / piezoresistive - image - 3
Add to favorites
Compare this product


Characteristics

Pressure type
relative, atmospheric, differential
Technology
piezoresistive
Output
4-20 mA, 0-10 V
Electrical connection
M12 connector
Supply voltage
24 Vdc, 24VAC
Protection level
IP67
Applications
process
Other characteristics
compact, temperature-compensated
Pressure range

Max.: 5,000 Pa
(0.73 psi)

Min.: -5,000 Pa
(-0.73 psi)

Process temperature

Max.: 50 °C
(122 °F)

Min.: -20 °C
(-4 °F)

Description

Pressure, differential pressure and volume flow measuring transducers PREMASGARD® 212x The calibratable compact pressure transmitters of the PREMASGARD® 212x series are equipped with 8 switchable measuring ranges, 2 switchable output signals (16 devices in one) and with/without optional display. They are used for measuring above-atmospheric, below-atmospheric or differential pressures and volume flow in air. The piezoresistive measuring element is temperature-compensated and guarantees a high degree of reliability and accuracy. These pressure measuring transducers have a pushbutton for manual zero-point calibration and an adjustable offset. Applications are found in cleanroom, medical and filter engineering, in ventilation and air conditioning ducts, in spray booths and large-scale catering facilities, in filter monitoring and level measuring or frequency converter triggering. Media measured with these pressure transducers are air (non-precipitating) or other gaseous, non-aggressive, non-combustible media. The differential pressure sensors are supplied including an ASD-06 connection set (2 m connection hose, two pressure connection nipples, screws).
