Electric band heater MH-304M

waterproofinsulated

Mica Insulated Nozzle Heater With Special Cable ConnectionMH-304MMica Insulated Heaters Used in the nozzles on injection molding machines, input of manifolds and various applications. These more productive barrel nozzle heaters, which have waterproof propperty, have to be mounted tigthly to the tips and worked with remote controller. Available with different cable lengths and lead exits. Technical Specification - Diameter : - Min. Ø30mm Max. Ø80mm Length: - Min 22mm Max. 150mm Voltage: - 230/400 V Wattage : - Max. 3,5 -4,5 W/cm² Working Temperature: - 350 °C Housing Material: - Stainless Steel or Aluminised Sheet Insulation Material: - 800-1000 °C Mikanite Resistance Winding Wire: - 60/15 NiCr 1200°C Energy Connection : - Ni GLS Cable Resistant to 400ºC or plug sockets
