Pleated filter box DUG-MAB PLUS, DUG-DAB PLUS

HEPAfor airaluminum

INTEGRATED HEPA TERMINAL FILTERS WITH LOW PRESSURE DROP The DUG-MAB PLUS and DUG-DAB PLUS low pressure drop terminal filters are certified as H14 efficiency in accordance with EN 1822. Due to their lower pressure drops compared to standard models, they consume less energy for the duration of their service life. They are ideal for use in sterile environments with laminar vertical airflow and the strictest cleanliness requirements (ISO 14644-1 classes 9 to 1); being extremely practical, they have revolutionised installations in cleanrooms in even the most demanding of industry settings: pharmaceutical, micro-electronics and electronics, food, aeronautical and chemical sectors. - Manufactured in an ISO 7 environment, individually scan-tested and packaged in an ISO 5 environment; - Water-repellent, micro-fibreglass filter media; - Equally spaced continuous thermoplastic spacers (mini-pleats); - Bicomponent polyurethane sealant; - Extruded anodised aluminium frame attached to a one-piece plenum made from self-extinguishing, stamp-formed polystyrene or aluminium and with a circular collar; - Painted aluminium protection grid on both sides; - CE certification.
