Perforating machine MB series

The sturdiness and simplicity of the machine guarantees trouble free operation in mass production. MB10 driven by electronic motor, which allows to vary speed. It is therefore suitable for the most part of perforating works. MB S driven by normal motor, with fixed speed and perforating rod automatic stop. Technical Data Adjustable speed from 0 to 650 r.p.m. (MB10) Fixed speed 570 r.p.m. (MB S) Adjustable feed from 1,5 to 16 mm. Rectilinear jaw feeding Feed adjustment by millimetric regulator Absorbed power max kW 0,5 Power supply three-phase 400 Volt 50/60 Hz (MB S) Power supply single-phase 230 Volt 50/60 Hz (MB10) Optional Exhauster with Filter (MB 10 – MB S) Brushless motor with automatic positioning (MB10) Machine weight Kg. 103 (MB10 C A) Machine weight Kg. 74 (MB10 – MB S)
