Gear hydraulic motor 2ME series aluminumcast iron
Add to favorites
Compare this product
Characteristics
- Technology
- gear
- Other characteristics
- cast iron, aluminum
- Pressure
280 bar
(4,061 psi)- Rotational speed
Max.: 4,000 rpm
(25,132.74 rad.min-1)Min.: 600 rpm
(3,769.91 rad.min-1)- Torque
Max.: 70 Nm
(51.63 ft.lb)Min.: 0 Nm
(0 ft.lb)- Displacement
4.6 cm³
(0.16 US fl oz)
Description
High volumetric efficiency achieved by floating bushings and axial compensation.
Integral gear with 12 teeth.
Double shaft seal.
Available with flanges, shafts and ports for the main European, German and American standards.
Available supports with bearing.
Wide range of rear covers with built-in valves.
Air compressor drive release:
electric or manual motor speed control;
electric venting valve.
Fan drive release:
proportional electric valve to control the speed of the motor;
4/2 ON-OFF electric valve to reverse the rotation.
Reversible release:
available also with internal drain.
