Current test bench SXGK HV/LV

voltagepower factorautomatic

SXGK Series HV/LV Switch Cabinet Test Bench is mainly applied for ex-work energized testing for high voltage and low voltage cabinet manufacturers. The test bench could provide various AC/DC power source, in order to detect switch cabinet. Features ♦ Reading directly: Digital meters to display current, voltage, power factor test value. ♦ Measuring accurately: High precision, test value is accurate. ♦ Full protections: Each circuit is with air switch protection. ♦ Portable: Small size, light weight, easy to move. Specifications Main Technical specifications: ♦ Input: 3 phase 4 line AC 380V ♦ Output voltage and current: 3 phase AC 0-50A output (10V, adjustable) one group 3 phase AC 100V output (fixed value) one group ♦ AC operating voltage output is AC 0-380V, 220V, the current is conventional and adjustable. ♦ DC operating voltage output DC 0-300V adjustable. ♦ Single phase AC 220V output (fixed value, plug type) two groups ♦ 3 phase 4 line AC 380V output (fixed value, wiring port) one group. ♦ Necessary output units to be increased output protection, and equipped with air switch. ♦ Power supply: AC 110V/115V/120V/127V/220V/230V/240V is optional ♦ Input frequency: 50Hz/60Hz is optional
