Compression testing machine SM-8006

tensilefatiguehardness

This tester is suitable for the compression testing, the hardness testing and the fatigue testing of polyfoam,sponge of seats, because of using the programmable software for the control, and the servo motor for the driving, the tester can satisfy the A,B,C three type of testing methods stipulated in the GB/T10807-2006. Application Electrical terminal tensile test Small plastic shell of electrical parts press resistance test Drink package bursting test Keyboard cap tensile test GB/T10807-2006 ISO 2439: 1997,ASTMD3674,JISK6400-2004 Specification Model - SM-RS-8006 Capacity (optional) - 10N,20N,50N,100N,200N, 500N Unit (switchable) - N, Kgf, Lbf Load resolution - Pin dial type 1/200, Digital type 1/1000 Load accuracy - ±1% Stroke (exclude the grips) - 150mm Effective width - 130mm Test speed - 10~150mm/min Speed accuracy - ±1% Motor - AC Motor Indicator - Need to choose by user (pin dial indicator or digital indicator) Main unit dimension (WxDxH) - 320x300x590mm Main unit weight - 26Kg Power supply - AC220V 3A or specified by user
