Driver drill SCANTOOL 16AT
electric

Driver drill - SCANTOOL 16AT - Scantool Group - electric
Driver drill - SCANTOOL 16AT - Scantool Group - electric
Driver drill - SCANTOOL 16AT - Scantool Group - electric - image - 2
Driver drill - SCANTOOL 16AT - Scantool Group - electric - image - 3
Driver drill - SCANTOOL 16AT - Scantool Group - electric - image - 4
Add to favorites
Compare this product


Characteristics

Type
driver
Power source
electric
Rotational speed

Max.: 2,740 rpm
(17,215.9 rad.min-1)

Min.: 180 rpm
(1,131 rad.min-1)

Power

750 W

Voltage

400 V

Drilling diameter

Max.: 20 mm
(0.79 in)

Min.: 1 mm
(0.04 in)

Description

SCANTOOL 16AE & 16AT are professional drill presses for workshop and industry Standard features: Morse Taper No. 2 Reversible spindle rotation Complete with auto lock chuck Separate emergency stop and working light For max. safety when changing the belt speed the machines are supplied with safety switch. Safety guard complete with micro switch The Scantool drill presses are specially produced by one of the largest factories in the world, using advanced technology on semi-automatic production lines The table is tilt-able with degree scale. 400 V models are reversible. Competitively priced. Product Specifications Rpm 180-2740 Voltage 3x400V - 50 Hz Motor (HP) 1,0 Motor (kW) 0,75 Drilling Capacity (ø mm) 1-20 Drill chuck (mm) 16 Throat depth (mm) 190 Swing Capacity (mm) 420 (14") Max. distance spindle/table (mm) 465/685 Size of table (mm) 285x285 Size of base (mm) 480x270 Max. tilt of table (+/-) 45° Max. spindle travel (mm) 80 Number of spindle speeds 12 Reversible 1 Bench model 1 Height (mm) 1065 Net weight (kg) 61
