Thermally conductive material OC-9100

OC-9100 is a thermally conductive phase change material coated on polyimide film. The liquid phase of the material can fill interface irregularities with much higher efficiency than traditional gap filler while the polyimide layer offers excellent anti-pierce and dielectric properties. OC-9100 is RoHS compliant and conforms to halogen-free standard. It is naturally tacky and additional adhesive is generally not required. Features and Benefit Thermally conductive phase change material Excellent anti-piercing properties Excellent dielectric properties Naturally tacky RoHS compliant Halogen-free Color - White Thickness Range [inch/(mm - 0.01(0.25)~0.02(0.50) Thermal Conductivity [W/mK] - 1 Phase Change Temperature [°C] - 50°C – 65°C Operation Temperature [°C] - -40°C~130°C Halogen-Free [under 700ppm] - Yes
