Fieldbus tester MTC2 R7

partial dischargesurge impulsecompatibility

• The fastest partial discharge test of all times thanks to patented 50 Hz pulse-frequency technology • Unsurpassed reliable winding fault detection due to the new, patented peak-to-peak measurement method • The outstanding Full-HD touch display measures 15.6″ and enables optimal viewing and operation • Fully integrated RLC test • 4 test connections in four-wire technology + 1 frame connection • Unrivaled fully automatic test method switching to all test connections • Virtually unlimited compatibility thanks to built-in Windows 10® | 11® PC • Various interfaces for remote control (Ethernet, RS232, fieldbus) • Unique test method diversity thanks to modular configuration and expansion! The latest hardware technologies paired with state-of-the-art .NetCore software come into play. This significantly increases the accuracy of the individual test methods and of the measurement speeds. The MTC2 R7 is the high-end device for testing windings, coils and armatures. SCHLEICH PATENT: The surge voltage test is capable of a pulse frequency of up to 50 Hz. The test time of the partial discharge inception voltages can thereby be reduced by up to 75 %. SCHLEICH PATENT: The SCHLEICH “peak to peak” method for the detection of voltage-dependent winding faults has been completely revised and enables highly sensitive fault detection even in the case of coils with very high numbers of windings, connected in series or parallel.
