Industrial firewall TCSEFEC23FCF21

DIN rail

range of product - ConneXium Concept - Transparent Ready communication port protocol - Ethernet TCP/IP SSH HTTP HTTPS SNMP SFTP SCP LLDP RS232 Port Ethernet - 10/100BASE-TX - 1 port(s) copper cable 100BASE-FX - 1 port(s) fiber optic Cybersecurity - Syslog protocol support IPSec user interface - Built-in firewall Encryption protocol - MAC addresses filtering Integrated connection type - Shielded RJ45 copper cable Duplex SC fiber optic Transmission support medium - Twisted shielded pairs cable CAT 5E for copper cable Multimode optical fiber Maximum cable distance between devices - 100 m copper cable Optic fiber length - 4 km 62.5/125 µm Attenuation - 0…11 dB (62.2/125 µm) 0…8 dB (50/125 µm) Ethernet service - Multicast filtering Syslog Communication service - Port monitoring Diagnostics run time - Signal contact Self test MAC notification Redundancy - Redundant network coupling Router redundancy [Us] rated supply voltage - 12...48 V Supply voltage limits - 9.6…60 V DC SELV 18…30 V AC SELV Power consumption in W - 8.3 W Electrical connection - Removable connector 6 ways power supply mounting support - 35 mm symmetrical DIN rail Marking - CE UL RCM Function available - System information Report IP Firewall list Configuration check Reachability test (ping) Alarms (Traps) Local signalling - 2 LEDs (green) for P1 P2 power supplies 1 LED (red) for fault 1 dual colour LED (green/yellow) for device status 1 dual colour LED (green/yellow) for memory key status 1 dual colour LED (green/yellow) for internal port status 1 dual colour LED (green/yellow) for serial port status Alarm output - 1 voltfree contact 1 A Alarm function - Power supply fault Data link status Switch fault
