More Energy Efficient, Plus Greater Throughput
The QuadCool burner features Selas’ proven SheetFlame ribbon design that provides a uniform flame pattern across the entire width of the burner. It was developed specifically for applications where continuous level, direct flame is required and where any distortion of the flame pattern would be detrimental to the finish of the product.
The SheetFlame ribbon uses an innovative port-free design, which eliminates striation lines in the treated substrate, unlike with ported ribbons. The SheetFlame ribbon projects even, continuous energy across the whole substrate, permitting fast line speeds and uninterrupted productivity.
Rugged Construction for Optimal Performance
The new Selas QuadCool surface modification burner features anodized aluminum construction with internal cooling tubes on 4 sides and flow in any direction. Heat deflection is minimized to an industry leading <1/16”, achieving near perfect parallel energy distribution across any substrate. QuadCool will remain parallel to all backup rolls to within 0.002”, even during high temperature operation.
Engineered for Simple Retrofit, Replacement and Maintenance
Drop-in replacement ribbon packs make cleaning maintenance and BTU output changes fast and easy while the burner is still mounted on the machine. A wide variety of ribbon packs are available, making the QuadCool very versatile for any 2D application. With available quick disconnect water and fuel connections, removing the burner takes only seconds rather than minutes or hours. Manufactured from anodized aluminum, the QuadCool is available in any length up to 3.5m (140”).
