Magnetic separator SS100

metalprocessstainless steel

Stailnless Steel Separator inox Stokkermill SS100 is able to separate stainless steel particles from pre-treated materials, particularly in the recycling and valorization of electrical and electronic materials (WEEE), car fluff (ASR), Zurik and Zorba and crushing residues. The SS100 Stailnless Steel Separator is also used in the field of plastic recycling and regeneration, where it is very important to eliminate metal and ferrous impurities to safeguard the extrusion and molding processes. The SS100 is available in different sizes and magnetic field strengths and can be cascade-configured where extremely high output purity standards are required. The high coercive force of SS100 allows the separation of small stainless steel parts in the order of 3-5mm.The separation of stainless steel particles from is a challenge for the recycling and recovery industry. The stainless-steel alloy is protected by an extremely thin layer of oxides. If the layer is broken in consequence of a process like granulation, shredding or impacts, the non-magnetic becomes a weak magnetic alloy which can be captured by the magnetic field of the cylinder allowing the separation within certain limits and respecting certain conditions. The smaller are the fragments of weak magnetic metal the lower will be the magnetic attraction capacity. This means that the best results can be achieved with particles >= 1 mm. The highest efficiency of the magnetic field can be reached within 10 mm from the magnetic cylinder is extremely important to distribute properly the materials in a thin layer on the magnetic cylinder.
